BC Racing BR Series Coilovers (YG-02-BR) for Tesla Model 3 AWD

Overview

The BC Racing BR Series YG-02-BR is a height adjustable coilover kit for the Tesla Model 3 AWD. BC Racing uses the same kit for the Model Y AWD.

BR Series coilovers use a monotube damper with a linear piston, 30 clicks of damping adjustment (compression and rebound together), and ride height adjustment that is independent of spring compression. BR Series kits are fully rebuildable, and BC Racing offers custom spring rates and Swift Spring upgrades.

Fitment

BC Racing lists YG-02-BR for the 2017 to 2023 Model 3 AWD and Model Y AWD (the same kit), and a separate kit, YG-11-BR, for the 2024 and newer Model 3 AWD. Model 3 AWD cars start in 2018.

What's Included

• BC Racing BR Series coilover kit, kit number YG-02-BR
• Front and rear dampers with BC Racing springs at the standard rates listed below
• Front upper mounts (rubber). The rear reuses the factory upper mounts

Specs

• Brand: BC Racing
• Series: BR
• Kit number: YG-02-BR
• Damper design: Monotube, linear piston
• Damping adjustment: 30 clicks, compression and rebound together
• Ride height adjustment: Independent of spring compression
• Standard spring rate, front: 10 kg/mm
• Standard spring rate, rear: 11 kg/mm
• Front upper mount: Rubber (standard configuration)
• Rear upper mount: Uses the factory mount
• BC spring part numbers: 62-235-10 front, 110-99-220-11-V rear
• Rebuildable: Yes

Part Numbers

• BC Racing kit number: YG-02-BR
• BC Racing full part number (standard configuration): YG-02-BR-RS

Warranty

BC Racing covers the BR Series against manufacturer defects. BC Racing's own website currently shows two different terms for the BR Series (one year on the series page and two years on the product page), so we will confirm the current term with BC Racing for your order. BC Racing asks owners to register the warranty with the serial number, purchase receipt, and warranty card.

Install with RideRite

RideRite is a mobile suspension install service in the San Francisco Bay Area. We come to you at home or at work, so there is no need to drop your car off anywhere.

• We install the coilovers at your location.
• A wheel alignment is required after install. RideRite does not perform alignments, so plan to book one with an alignment provider soon after the install. Driving for long on an unaligned car can wear tires quickly.
• After install, ride height is set to your target.

Book an install or request a quote at riderite.us
